Direct Metal Laser Sintering 3d Metal Printing / Metal Injection Moulding

China Direct Metal Laser Sintering 3d Metal Printing / Metal Injection Moulding supplier

Large Image :  Direct Metal Laser Sintering 3d Metal Printing / Metal Injection Moulding

Product Details:

Place of Origin: Shenzhen,China
Brand Name: StrongD
Certification: ISO9001:2008, SGS-CSTC
Model Number: Custom made

Payment & Shipping Terms:

Minimum Order Quantity: 1pcs
Price: negotiable
Packaging Details: Carton with foam wrapped, PE bags
Delivery Time: General 5-8 working days
Payment Terms: T/T, Western Union,paypal, MoneyGram
Supply Ability: 50pcs/Month, 1cm3/hour
Contact Now
Detailed Product Description
Material: Stainless Steel 316 L Materials Morphology: Powder
CNC Machining Or Not: Not Micro Machining Or Not: Not
Quotation Leadtime: Within 24 Hours Business Type: Manufacturer&factory
Tolerance: +/-0.05mm Price: Reasonable And Negotiate
Avaliable Files: Step/stp/igs/x_t/stl Material Capabilities: Cobalt-chromium Alloy,stainless Steel 316,titanium





Direct Metal Laser Sintering 3d Metal Printing / Metal Injection Moulding





Direct Metal Laser Sintering, Metal Selective Laser Sintering (SLS)



Direct metal laser sintering (DMLS) is an additive metal fabrication technology developed by EOS out of Munich, Germany, sometimes also referred to by the terms selective laser sintering (SLS) or selective laser melting (SLM). The process involves use of a 3D CAD model whereby a .stl file is created and sent to the machine’s software. A technician works with this 3D model to properly orient the geometry for part building and adds supports structure as appropriate. Once this "build file" has been completed, it is "sliced" into the layer thickness the machine will build in and downloaded to the DMLS machine allowing the build to begin.





Advantages





1. DMLS is also one of the few additive manufacturing technologies being used in

production. Since the components are built layer by layer, it is possible to design internal features and

passages that could not be cast or otherwise machined.



2. Compared with traditional manufacturing techniques, the speed of DMLS is the most

obvious because no special tooling is required and parts can be built in a matter of hours.



3. Complex geometries and assemblies with multiple components can be simplified to fewer parts with a

more cost effective assembly. DMLS does not require special tooling like castings, so it is convenient for

short production runs.



4. DMLS allows for more rigorous testing of prototypes. Since DMLS can use most alloys, prototypes can now

 be functional hardware made out of the same material as production components.





Applications



·  Metal parts, fire test parts, fixture direct manufacturing and model demonstration test.

·  Development of new products.

·  Creative design and display of culture, creativity, clothing, household goods and other.

·  Product design, rapid production of high-precision injection molds.

·  Research and development of implants, teeth, skull repair, prosthetics and medical

   equipment.





Technical Specifications for Direct Metal Laser Sintering



Technique Specifications of EOSINT M 280

Equipment

Building volume

250 mm x 250 mm x 325 mm

(9.85 x 9.85 x 12.8 in)

Direct Metal Laser Sintering 3d Metal Printing / Metal Injection Moulding

building platform 9.85 x 9.85 x 12.8 in

Laser type

Yb-fibre laser, 200 W oder 400 W (optional)

Precision optics

F-theta-lens, high-speed scanner

Scan speed

up to 7.0 m/s (23 ft./sec)

Variable focus diameter

100 - 500 μm (0.004 - 0.02 in)

Power supply

32 A

Power consumption

maximum 8.5 kW / typical 3.2 kW

Nitrogen generator

integrated

Compressed air supply

7,000 hPa; 20 m3/h (102 psi; 706 ft3/h)

Argon supply

4,000 hPa; 100 l/min

(58 psi; 3.5 ft3/min)(optional)
