Precision Medical Device Prototyping CNC Plastic Machining Services

China Precision Medical Device Prototyping CNC Plastic Machining Services supplier

Large Image :  Precision Medical Device Prototyping CNC Plastic Machining Services

Product Details:

Place of Origin: shenzhen china
Model Number: custom made

Payment & Shipping Terms:

Minimum Order Quantity: 1pcs
Price: negotiable
Packaging Details: by carton
Payment Terms: T/T, Western Union,paypal
Contact Now
Detailed Product Description



Precision Medical Device Prototyping CNC Plastic Machining Services





Inspection Equipment-Three coordinate measuring



For its high precision flexible three coordinate measuring technology and excellent digital capability, become

a modern manufacturing especially mold industrial design, development, manufacture and quality assurance.

YanHua company now in U.S. FARO company produces the Platinum FaroArm 2.4 m joint arm type measuring

 instrument, measurement accuracy of + / - 0.03 mm.

Three coordinate measuring machine can be applied to 3 d digital analog input, will the molding samples or

related to the da location, size, shape tolerance, curve and curved surface are compared, and measuring the

 output graphical reports, intuitive clearly reflect the quality of the products, thus forming a complete sample test

 report.





Features:

  1. prototype: CNC machining,the  materials for plastic or metal sheet.
  2. Mould: epoxy resin mold or ABS mold.
  3. Injection:RIM,the material is PU resin AXSON 875/900 - RIM, HD - RIM4210/1100
  4. Post-processing: Plating , painting , silk-screen .
  5. Inspection: tooling fixture, three coordinate measuring.
  6. Precision control





Prototype parts: main location hole / 1000 mm + / - 0.3 mm, general installation hole / 1000 mm + / - 0.5 mm,

other size + / - 1.0 mm / 1000 mm.
Note type: the main location hole / 1000 mm + / - 0.5 mm, general installation hole / 1000 mm + / - 0.8 mm,

 other size + / - 1.5 mm / 1000 mm.





Service Step for a Project



Precision Medical Device Prototyping CNC Plastic Machining Services



Precision Medical Device Prototyping CNC Plastic Machining Services
